Triumph Rocket 3 GT 2021 - Page 263

235
3. Release the two fixings and remove the number one cylinder ignition coil.
1. Ignition coil connections
2. Fixings
3. Number one cylinder ignition coil
4. Detach the rear caliper brake line from the ignition coil bracket. Discard the fir tree
clip.
NOTICE
Note the orientation of the number one cylinder ignition coil bracket for installation.
