Camshaft Cover – Removal
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Fuel Tank - Removal
• Remove the left hand Side Panels - Removal
• Evaporative Canister - Removal
• Remove the air filter, see Air Filter - Renew
Note the routing of the high tension cables to the spark plugs for installation.
Note the position and routing of the wires connected to the ignition coils for
installation.
1. Disconnect the high tension cables from the spark plugs.
2. Disconnect the two wires from the number one cylinder ignition coil.
