15. Engage the upper retaining clips of the radiator cowl into their slots, fit the fixings
and tighten to 4 Nm.
1. Fixings
2. Lower cowl
3. Retaining clips
Perform the following operations:
• Starter Drive Cover - Installation
• Starter Motor - Installation
• Battery Box - Installation
• Rear Suspension Linkage - Installation
• Swinging Arm – Installation
• Plenum - Installation (All Markets Except US) or Plenum - Installation (US
Markets Only)
