3. Position the service tools and bearing (marked side facing outwards) to the drag link
on a press.
4. Press in the new bearing until the service tool contacts the drag link.
1. T3880629 - Bearing Installer Handle
2. T3880511 - Needle Bearing Installer 6.5mm
3. Needle roller bearing
5. Using the same service tools, fit new seals to the drag link. Make sure the seals, when
fitted, are below the chamfer edge. 6. Repeat steps 4 to 5 for the other end.
Perform the following operations:
• Rear Suspension Linkage - Installation
• Rear Suspension Unit - Installation
• Catalytic Converter - Installation
• Battery - Installation
• Seat - Installation
