236
5. Release the four fixings and remove the ignition coil bracket. Discard the fixings.
1. Rear caliper brake line
2. Retaining fir tree clip
3. Fixings
4. Ignition coil bracket
6. Release the fixing and detach the rear brake master cylinder line from the
evaporative canister bracket. discard the fixing.
7. Release the fixings and detach the evaporative canister bracket from the fuel tank
front mounting bracket. Discard the fixings.
