275
3. Check the alignment marks on the front end of the camshaft journals are pointing
inwards. If they are pointing outwards, rotate the crankshaft anticlockwise one
complete turn.
1. Camshaft alignment marks
2. Exhaust camshaft
3. Inlet camshaft
NOTICE
The alignment mark on the flange of T3880501 - Crankshaft Locking Pin is in line with
the gear tooth at the other end of the service tool. Use this alignment mark as a guide
when inserting the service tool.
