282
18. Continue to rotate the crankshaft anticlockwise to complete two revolutions and the
two gear teeth with an alignment marks are visible and central in the hole for the
crankshaft locking pin.
1. Crankshaft primary gear
2. Alignment marks
19. Check that there is tension in the camshaft drive chain and the slot at the camshafts
end are correctly aligned.
1. Camshaft timing slots
