Triumph Rocket 3 GT 2021 - Page 312

284
24. Reheck that there is tension in the camshaft drive chain and the slot at the camshafts
end are correctly aligned.
1. Camshaft timing slots
25. Recheck the tensioner plunger location against the camshaft drive chain tensioner
blade.
26. Remove service tool T3880501.
1. T3880501 - Crankshaft Locking Pin
2. Alignment mark
