301
4. Loosen the two accessible camshaft sprocket fixings. Do not remove the fixings at
this stage.
1. Fixings
5. Rotate the crankshaft until the remaining two fixings are accessible.
Do not rotate the crankshaft further once the four camshaft sprocket bolts have been
loosened. Rotation of the crankshaft with the four sprocket bolts loose will result in
valve to piston contact and serious engine damage.
6. Loosen the two remaining camshaft sprocket fixings.
7. Remove the camshaft drive tensioner (see Camshaft Drive Chain Tensioner -
Removal).
NOTICE
Note the orientation and position of the camshafts caps for installation.
Number the camshafts caps to make sure they are fitted to their original position and
orientation.
Each camshaft cap has two hollow dowels fitted to them. Note their positions for
installation.
