352
5. Carefully detach the fluid reservoir from the master cylinder spigot.
1. Reservoir
2. Master cylinder
3. Spigot
Clutch lever
NOTICE
Only disassemble the lever if it is to be replaced.
If the lever is to be replaced, The pivot assembly and push rod for the master cylinder
must be removed from the original lever and fitted to the new lever.
Note the setting of the lever adjuster to ensure it is returned to the same position on
installation.
1. Remove the lock nut from the lever pivot bolt.
2. Remove the lever pivot bolt.
3. Release the lever from the master cylinder assembly and remove the dust seal.
NOTICE
The service tool T3880636 is required to remove the lever pivot sleeve.
