354
5. Position the lever assembly to the support piece as shown.
1. Brake lever
2. Pivot
3. Support piece
6. Position the mandrel and extractor to the lever and press out the pivot sleeve from
the lever assembly.
1. Mandrel
2. Support piece
3. Extractor
4. Lever
5. Pivot
6. Return spring
