358
6. Place the lower surface of the lever onto the support piece, and then using a press
push the pivot sleeve through the lever pivot until the mandrel touches the upper
brake lever surface.
1. Mandrel
2. Support piece
3. Extractor
4. Lever
5. Pivot
6. Return spring
7. Support the brake kever, hold the mandrel and turn the installer piece anticlockwise
to release it from the mandrel.
1. Mandrel
2. Installer piece
3. Thread
