360
13. Check lever operation and make sure the rubber seal is still correctly seated.
Brake Fluid Reservoir
1. Check the condition of the spigot seal in the reservoir. Replace if damaged.
2. Fit the reservoir onto the master cylinder spigot.
1. Reservoir
2. Master cylinder
3. Seal
4. Spigot
3. Check the two O-rings on the reservoir fixing. Replace if damaged.
4. Fit the reservoir fixing and tighten to 25 Nm.
5. Fit the sealing screw to the reservoir mounting fixing and tighten to 6 Nm.
