6. Fit the clutch lever to the master cylinder. Tighten the pivot bolt to 6 Nm and tighten
the lock nut to 6 Nm.
7. Fit the master cylinder (see Clutch Master Cylinder – Installation)
8. Bleed the clutch (see Bleeding the Clutch).
Clutch Master Cylinder – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
To prevent body damage, do not spill brake and clutch fluid onto any area of the
bodywork or the brake and clutch reservoirs.
1. Locate the clutch master cylinder to the handlebars and fit the clamp, do not fully
tighten at this stage.
When fitting the clutch master cylinder, care must be taken to avoid trapping switch
housing harness between handlebar and reservoir clamp.
