Triumph Rocket 3 GT 2021 - Page 390

362
2. Align the straight edge on the clamp to the alignment mark on the handlebar (as
shown in the illustration below) and tighten the fixings (upper one first) to 8 Nm.
1. Alignment mark
2. Straight edge
3. Clamp
3. Connect the clutch hose to the master cylinder incorporating new sealing washers to
each side of the union. Tighten the union bolt to 25 Nm.
1. Union bolt
2. Sealing washers
3. Clutch hose
