Triumph Rocket 3 GT 2021 - Page 409

381
4. Assemble the innermost friction and steel plates to the pressure plate in the same
order and orientation as noted for removal.
1. Pressure plate
2. Inner friction plates
3. Inner steel plate
5. While holding the innermost friction and steel plates in position, invert the pressure
plate and locate it onto the clutch centre.
1. Locating the Pressure Plate
