382
6. Make sure the pressure plate ramps engage correctly with the clutch centre.
1. Pressure plate ramps
NOTICE
Do not allow the clutch centre and pressure plate to separate at this point as this may
cause the innermost steel plate to disengage from the pressure plate splines.
7. Holding the clutch centre and pressure plate assembly together, invert the assembly
and place on a suitable support. Make sure the assembly rests on the pressure plate
and not on the under side of the clutch centre.
1. Support
2. Clutch centre (underside)
3. Pressure plate
