NOTICE
During the next instruction step, the release plate fixings should be tightened until a
small amount of preload is applied to the springs. The amount of preload applied
should be sufficient to prevent the clutch centre and pressure plate from separating,
while allowing movement/rotation of the friction plates.
8. Fit the spring seats, springs and release plate to the clutch centre and pressure plate
assembly and secure with the three fixings. Evenly and progressively tighten the
release plate fixings until a small amount of spring preload is applied. Do not fully
tighten the fixings.
1. Fixings
2. Release plate
