408
1. Use high flash-point solvent to clean the crankcase mating faces. Wipe the surfaces
clean with a lint-free cloth.
2. Make sure that the two locating dowels are in position in the upper crankcase and
the oil dowel is fitted to the bearing cap with the O- ring uppermost.
1. Dowels
2. Oil dowel
Do not use excessive amounts of sealer. The extra sealer may become dislodged and
could block the oil passages in the crankcases causing severe engine damage.
3. Apply a 2 mm diameter bead of silicone sealant (at the factory, ThreeBond 1216E is
used) to the transmission cover mating faces. The sealant is to be 2.5 mm inside of
the external edges.
