412
5. Remove the dead shaft clamp blanking plug. Discard the washer.
1. Hollow dowels
2. Solid dowel
3. Washer
4. Plug
6. Remove the three hollow dowels for the upper crankcase.
7. Remove the solid dowel for the clutch cover.
8. Remove the crankshaft locking pin plug from the crankcase.
1. Hollow dowels
2. Solid dowel
3. Locking pin plug
