413
Transmission Cover
1. Remove and discard the two fixings securing the transmission oil spray bar.
2. Remove the spray bar from the transmission cover and discard its O-ring.
1. Fixings
2. Oil spray bar
3. O-ring (oil spray bar)
3. Remove the two solid dowels for the oil tank cover.
4. Release the fixing and remove the oil filler tube.
1. Solid dowel
2. Fixing
3. Oil filler tube
