411
Remove the components from the original crankcase as described in the procedure
below.
Perform the following operations:
• Engine - Removal
• Clutch - Removal
• Alternator Rotor - Removal
• Output Shaft - Removal
• Input shaft - Removal
• Gear Change Shaft and Selector Drum - Removal
• Barrels - Removal
Lower Crankcase
1. Remove the oil pump (see Oil Pump - Removal).
2. Remove the two solid dowels for the oil pump.
1. Dowels
2. Lower crankcase
3. Remove the four hollow dowels for the sump.
4. Remove the solid dowel for the alternator cover.
To Next Page
