467
Perform the following operations:
• Output shaft - Installation
• Engine - Installation
• Fuel Tank - Installation
• Battery - Installation
• Seat - Installation
Output Shaft – Removal
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
Only the torsional damper and the retaining plate is to be removed from the output
shaft.
The output shaft assembly is not to be disassembled. If an item of the output shaft
requires replacing, the complete output shaft assembly must be replaced.
Make sure the gear selection is in neutral before removing the output shaft.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Fuel Tank - Removal
• Engine - Removal
• Throttle Body - Removal
• Transmission Cover - Removal
