Triumph Rocket 3 GT 2021 - Page 498

470
5. Progressively release the transmission bearing cap fixings in the sequence shown
below.
Transmission Bearing Cap Release Sequence
6. Remove the transmission bearing cap.
NOTICE
Note there is a washer between the output shaft and the upper crankcase for
installation.
Note the position of the two gear selector forks for installation.
7. Carefully lift out the output shaft, torsional damper and output retaining plate from
the upper crankcase.
NOTICE
Note that the retaining plate has an OUT marking and it is facing towards the torsional
damper for installation.
