474
7. Remove the transmission cap and the output shaft.
Shim Chart
Shim
Shim Thickness (mm)
Measured Range
1
0.30
0.50 to 0.59
2
0.40
0.60 to 0.69
3
0.50
0.70 to 0.79
1 + 1
0.60
0.80 to 0.89
1 + 2
0.70
0.90 to 0.99
2 + 2
0.80
1.00 to 1.09
2 + 3
0.90
1.10 to 1.19
Output shaft – Installation
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
If fitting a new output shaft and/or a new crankcase, refer to Output Shaft Bearing
Measuring and Shim Selection to select the correct shim prior to fitting to the output
shaft.
