Triumph Rocket 3 GT 2021 - Page 514

486
NOTICE
Note the orientation of the retaining plate for installation.
3. Release the fixing and remove the selector fork shaft retaining plate. Discard the
fixing.
1. Fixing
2. Retaining plate
NOTICE
Prior to removal, mark, or make a note of the relative positions and orientation of each
selector fork in the selector drum.
1. Spring
2. Fixing
3. Hardened washer
4. Detent arm
