487
4. Withdraw the selector fork shaft and noting their position and orientation, collect the
three selector forks.
1. Selector fork shaft
2. Selector fork (input shaft)
3. Selector fork (output shaft)
4. Selector fork (output shaft)
Selector Forks and Drum Inspection
Inspect all bearings for damage or wear. Renew as necessary.
Inspect the selector forks and selector grooves for wear beyond the service limits. Renew
the components as necessary.
For specifications refer to Transmission.
