489
2. Fit the selector fork shaft retaining plate, as noted for removal, and tighten the new
fixing to 10 Nm.
1. Fixing
2. Retaining plate
3. Fit the detent arm, the hardened washer and tighten the new fixing to 10 Nm.
4. Fit the detent arm spring as noted for removal.
1. Spring
2. Fixing
3. Hardened
washer
4. Detent arm
