41. Using service tool T3880506 remove the outrigger rear dowel. Leave service tool
T3880506 in to support the outrigger.
1. Dowel
2. T3880506 - Outrigger dowel removal
42. With the aid of an assistant, remove service tool T3880506 and pivot the outriggers
rearwards. Lower the engine to access the harness connectors at the rear of the
engine.
43. Disconnect the following harness connectors:
• Engine subharness
44. Lower the engine down.
45. Fit service tool T3880506 in to support the outrigger.
