554
3. Using a suitable hoist, support the rear frame and outrigger assembly.
4. With the aid of an assistant, remove service tool T3880505 from the frame.
1. T3880505 - Main frame support
2. Swinging arm mountings
3. Support bar
5. With the aid of an assistant, remove service tool T3880506 and pivot the outriggers
rearwards. Align the engine mounting points with the corresponding positions on the
frame.
6. Tighten the engine mounting bolts in the following two stages:
