555
Stage 1
7. Insert the cylinder head front mounting bolt from the right hand side with a washer
between the bolt and the frame.
8. Using service tool T3880181 tighten the cylinder head front frame adjuster to 3 Nm.
9. Fit the washer and new lock nut to the cylinder head front mounting bolt. Do not
fully tighten at this stage.
10. Using service tool T3880181 tighten the crankcase front frame adjuster to 3 Nm.
1. Cylinder head front frame adjuster
2. Crankcase front frame adjuster
