557
19. Fit the swinging arm spindle from the left hand side.
1. Pivot
2. Swinging arm
20. Fit the swinging arm bolt from the right hand side. Do not fully tighten at this stage.
Stage 2
21. Counter hold the swinging arm spindle and tighten the bolt to 100 Nm.
1. Bolt
