46. Attach the purge valve bracket to the cylinder head and tighten the fixings to 10 Nm.
1. Fixings
2. Purge valve bracket
47. Incorporating new sealing washers to either side of the union, fit the brake line to the
ABS modulator as noted for removal. Tighten the brake line union to 25 Nm.
48. Release the brake line union for the rear brake master cylinder at the ABS hydraulic
modulator. Discard the sealing washers.
