563
1. Brake line union
2. Brake line (rear master cylinder)
49. Connect the ABS modulator multiplug (see ABS Electrical Connectors).
50. Route the secondary air injection hoses as noted for removal, fit the silencer box and
tighten the fixings to 5 Nm.
1. Fixings
2. Secondary air injection silencer box
51. Route the alternator and regulator/rectifier harnesses to the regulator/rectifier as
noted for removal.
52. Rout the gear position sensor as noted for removal.
