Triumph Rocket 3 GT 2021 - Page 789

751
4. Remove the ring of fixings securing the fuel pump mounting plate to the fuel tank.
1. Fixing
2. Fuel pump mounting plate
5. Detach the pump assembly from the fuel tank.
6. Disconnect the fuel level sensor from the fuel pump assembly harness.
1. Electrical connector
7. Remove the fuel pump assembly and discard the fuel pump plate seal.
