Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Fuel Tank - Removal
• Fuel injectors and Fuel Rail - Removal
1. Disconnect the throttle actuator motor multiplug.
2. Disconnect the throttle position sensor multiplug.
1. Throttle actuator multiplug
2. Throttle position sensor multiplug
