803
4. If required, detach the electrical connector and brake line clamp from the ignition
coils bracket. Discard the fixing.
5. Remove and discard the fixings on the right hand side of the ignition coils bracket.
1. Electrical connector
2. Fixing (brake in clamp)
3. Fixing (bracket)
6. Remove the fixing on the left hand side and remove the ignition coils bracket.
Discard the fixing.
1. Fixing
2. Ignition coil bracket
