Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
1. Fit the ignition coils bracket to the motorcycle frame. Fit a new fixing on the left hand
side and tighten to 9 Nm.
1. Fixing
2. Ignition coil bracket
2. Fit the ignition coils bracket to the motorcycle frame. Fit two new fixings on the right
hand side and tighten to 9 Nm.
3. If removed, attach the electrical connector to the ignition coils bracket.
