4. Attach the brake line clamp to the ignition coils bracket and tighten its new fixing to
5 Nm.
1. Electrical connector
2. Fixing (brake in clamp)
3. Fixing (bracket)
5. Route the high tension cables as noted for removal and connect them to the spark
plugs.
6. Fit the ignition coils to their brackets and tighten the new fixings to 5 Nm.
