806
7. Connect the six wires to the ignition coils as noted for removal.
1. Ignition coil connections (Number one cylinder)
2. Ignition coil connections (Number two cylinder)
3. Ignition coil connections (Number three cylinder)
4. Fixings
Perform the following operations:
• Evaporative Canister - Installation
• Fuel Tank - Installation
• Battery - Installation
• Seat - Installation
Coolant Temperature Sensor – Removal
Make sure the motorcycle is stabilised and adequately supported.
A correctly supported motorcycle will help prevent it from falling.
An unstable motorcycle may fall, causing injury to the operator or damage to the
motorcycle.
