Triumph Rocket 3 GT 2021 - Page 860

822
2. Disconnect the gear position sensor electrical connector from the main harness.
1. Gear position sensor connector
2. Oxygen sensor connector
NOTICE
Note the routing of the gear position sensor harness for installation.
3. Route the gear position sensor harness through the frame to the gear position
sensor.
4. Release the fixings and remove the gear position sensor.
1. Fixings
2. Gear position sensor
