Triumph Rocket 3 GT 2021 - Page 953

915
• Twist Grip Position Sensor - Removal
NOTICE
The clutch switch is secured to its housing by two fixings. The clutch switch housing is
a press fit to the clutch master cylinder.
Note the orientation of the clutch switch for installation.
1. Carefully detach the clutch switch assembly from the master cylinder.
1. Clutch switch
2. Securing lugs
3. Location holes
2. Release the fixings, remove the clamp then detach and support the clutch master
cylinder.
