Triumph Rocket 3 GT 2021 - Page 954

916
3. Release the fixings, lift off the clamp then detach and support the front brake master
cylinder.
1. Fixings
2. Clamp
3. Master cylinder
NOTICE
Note the routing of the handlebar harnesses for installation.
4. Release the fixing and remove the cover on the left hand switch housing.
1. Fixing
2. Cover
3. Switch housing
