18. Slide over the retaining clip until it locks into position.
1. Right hand switch housing
2. Retaining clip
19. Fit the switch housing connectors.
20. Using a new cable tie, secure the switch housing wiring harness to the left hand
switch housing.
21. Locate the clutch master cylinder to the handlebars and fit the clamp, do not fully
tighten at this stage.
When fitting the clutch master cylinder, care must be taken to avoid trapping switch
housing harness between handlebar and reservoir clamp.
When fitting the clutch master cylinder, pull clutch lever fully in and check that it clears
the high beam trigger.
