Triumph Rocket 3 GT 2021 - Page 966

928
22. Align the straight edge on the clamp to the alignment mark on the handlebar (as
shown in the illustration below) and tighten the fixings (upper one first) to 8 Nm.
1. Alignment mark
2. Straight edge
3. Clamp
23. Attach the clutch switch assembly to the master cylinder as noted for removal.
1. Clutch switch
2. Securing lugs
3. Location holes
