Triumph Rocket 3 GT 2021 - Page 980

942
Perform the following operations:
• Seat - Removal
• Battery - Removal
• Upper Yoke - Removal
• Seat - Removal
• Battery - Removal
1. Use service tool T3880750 to remove the lock nut.
2. Remove the tab washer.
3. Use service tool T3880750 to remove the adjuster nut.
1. T3880750 - Headstock Service Tool
2. Lock nut
3. Tab washer
4. Adjuster nut
5. Dust seal
4. Remove the lower yoke from below the frame headstock.
Headstock Bearings - Removal
