General Information
73
An adhesive label will be fitted to the
wheel rim to indicate the position of the
tyre pressure sensor, which is near the
valve.
Note
The Tyre Pressure Monitoring System
(TPMS) is available as an accessory kit.
It must be fitted by your authorised
Triumph dealer.
The TPMS display on the instruments
will only be activated when the system
has been fitted.
Tyre Pressure Sensor Serial Number
The serial number for the tyre pressure
sensor is printed on a label attached
to the sensor. This number may be
required by your authorised Triumph
dealer for service or diagnostics.
When the tyre pressure monitoring
system is being fitted to the motorcycle,
make sure that your authorised Triumph
dealer records the serial numbers of the
front and rear tyre pressure sensors in
the spaces provided below.
Front Tyre Pressure Sensor
Rear Tyre Pressure Sensor
TPMS System Display
The tyre pressure warning
light works in conjunction
with the Tyre Pressure
Monitoring System (TPMS).
The warning light will illuminate when
the front or rear tyre pressure is below
the recommended pressure. It will not
illuminate if the tyre is over inflated.
When the warning light is illuminated,
the TPMS symbol indicating which is
the deflated tyre and its pressure will
automatically be shown in the tyre
pressure display.
A
15:53
FRONT
REAR
1.9
2.9
bar
bar
Front Tyre
Low
TPMS
2
2
1
4
3
1. TPMS warning light
2. Front tyre pressure indicator
3. Rear tyre pressure indicator
4. TPMS information tray message
The tyre pressure at which the warning
light illuminates is temperature
compensated to 20°C but the numeric
pressure display associated with it
is not. Even if the numeric display
seems at or close to the standard tyre
pressure when the warning light is on,
a low tyre pressure is indicated and a
puncture is the most likely cause.
