General| Displacement | 1200 cc |
|---|---|
| Bore x Stroke | 97.6 mm x 80 mm |
| Compression Ratio | 11.0:1 |
| Transmission | 6-speed |
| Front Tyre | 90/90-21 |
| Rear Tyre | 150/70 R17 |
| Seat Height | 870 mm |
| Fuel Capacity | 16 L |
| Dry Weight | 207 kg |
| Engine Type | Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin |
| Max Power | 89bhp (66.2kW) @ 7, 400rpm |
| Max Torque | 110 Nm |
| Final Drive | Chain |
| Frame | Tubular steel |
| Front Suspension | 250mm travel |
| Rear Suspension | 250mm rear wheel travel |
| Front Brakes | Brembo 4-piston radial monobloc calipers, ABS |
| Rear Brakes | Single 255 mm disc, Brembo 2-piston |
| Front Wheel | 21 x 2.15 in |
| Rear Wheel | 17 x 4.25 in |
