Triumph Speed Triple Handbook

105
Maintenance and Adjustment
Speed Triple R
1. Compression damping adjuster
The compression damping adjuster is
accessible from the left hand side of the
motorcycle. It is coloured gold and is situated
close to the rear suspension reservoir.
To adjust the rebound damping setting,
rotate the adjuster clockwise to increase
rebound damping and anti-clockwise to
decrease. Always count the number of clicks
anti-clockwise from the fully clockwise
position noting that the first stop (click
position) is counted as zero.
Note:
• The motorcycle is delivered from
the factory with the rebound
adjuster set at 17 clicks from the
fully clockwise position.
All Models
1
chcx_1
Warning
The rear suspension unit spring pre-load is
not rider adjustable. Any attempt to adjust
the spring pre-load could result in a
dangerous riding condition leading to loss
of control and an accident.

Triumph Speed Triple Specifications

General

Transmission	6-speed
Engine Type	Liquid-cooled, 12-valve, DOHC, in-line 3-cylinder
Front Suspension	Öhlins 43mm NIX30 upside down forks, adjustable compression, rebound and preload
Rear Suspension	Öhlins monoshock, adjustable compression, rebound and preload
Front Brakes	twin 320mm floating discs
Rear Brakes	Brembo single piston caliper, 220mm disc
Fuel Tank Capacity	15.5 litres
