How to Ride the Motorcycle
1. Engine stop switch
2. Starter button
3. Neutral indicator light
4. Choke
5. Ignition switch
To Stop The Engine
• Close the throttle completely.
• Select neutral.
• Turn the ignition switch off.
• Select first gear.
• Support the motorcycle on a firm
and level surface with the side stand.
• Withdraw the ignition key from the
ignition switch.
• Engage the steering lock (see
page 25).
To Start The Engine
• Release the steering lock.
• Check that the engine stop switch is
in the RUN position.
• Insert the ignition key and turn the
ignition switch to the ON position.
• Ensure that the transmission is in
neutral.
• Pull the clutch lever fully into the
handlebar.
• If the engine is cold, pull out the
choke, noting the following: Above
25°C air temperature, pull out the
choke to the first position. Below
25°C air temperature, pull out the
choke fully.
• If the engine is partly warm, pull out
the choke to the first position.
• Leaving the throttle completely
closed, push the starter button until
the engine starts.
• Release the clutch lever slowly.
• During warm-up, gradually push the
choke in a little at a time as
necessary to prevent the engine
from racing or stalling.
2
4
1
3
N
5
Caution
The engine should normally be stopped by
turning the ignition switch to the OFF
position. The engine stop switch is for
emergency use only. Do not leave the
ignition switched on with the engine
stopped. Electrical damage may result.

Triumph Speedmaster Specifications

General

Displacement	1200 cc
Bore x Stroke	97.6 mm x 80 mm
Compression Ratio	10.0:1
Max Torque	106 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Clutch	Wet, multi-plate assist clutch
Gearbox	6-speed
Rear Tyre	150/80 R16
Engine Type	Liquid-cooled, 8-valve, SOHC, 270°
Max Power	76.9 bhp (57.4 kW) @ 6, 100 rpm
Exhaust	2-into-2 exhaust system with twin silencers
Frame	Tubular steel
Rear Suspension	Twin shocks, adjustable preload
Front Brake	Twin 310mm discs, 2-piston floating calipers
Rear Brake	Single 255mm disc, 2-piston floating caliper
Front Wheel	32-spoke
Rear Wheel	32-spoke
Tank Capacity	12 L
